DT200L / DT230L

Linerless Printer Series • Small in Size • Powerful in Function!

The DT200L series supports linerless media printing with 203 dpi or 300 dpi printing resolution. A full line of optional accessories is available.

3 Years Warranty

  • Supports 203 dpi / 300 dpi printing resolution
  • Small footprint with a wall-mountable design for space optimization
  • The innovative easy-to-use auto-calibration button facilitates media
    detection and positioning.
  • Adjustable TPH print line to optimize printability
  • Multiple connection interfaces for multiple applications
  • Optional wireless connectivity: Bluetooth or Wi-Fi module
  • Supports linerless media

Brochure

Category:

Description

Specs
Print Method
Direct Thermal
Resolution
203 dpi (8 dots/mm) / 300 dpi (12 dots/mm)
Print Speed
6 IPS (152 mm/s) / 4 IPS (102 mm/s)
Print Width
2.12” (54 mm); 2.24” (57 mm)
Print Length
Min. 0.98” (25 mm); Max. 4.72” (120 mm)
Processor
32 Bit RISC CPU
Memory
Flash : 128 MB (60 MB for user storage); SDRAM : 32 MB
Interfaces
USB 2.0 • Serial port: RS-232 (DB-9) • Ethernet 10/100 Mbps
Ribbon
N/A
Control Panel
• Two LEDs : Ready, Status • Power on / off button • Calibration button • Control key : FEED
