Description
Specs
Print Method
Direct Thermal
Resolution
203 dpi (8 dots/mm) / 300 dpi (12 dots/mm)
Print Speed
Up to 6 ips (152 mm/s) / up to 5 ips (127 mm/s)
Print Width
2.12” (54 mm) / 2.24” (57 mm)
Print Length
Min. 0.12” (3 mm); Max. 539.37” (13,700 mm) / Min. 0.12” (3 mm); Max. 236.22” (6000 mm)
Processor
32 Bit RISC CPU
Memory
128 MB Flash (34 MB for user storage) / 128 MB SDRAM
Interfaces
• USB 2.0 (Type B) • Serial port (RS-232) • Ethernet 10/100 Mbps • USB Host (A-Type)
Ribbon
–
Control Panel
• Two LEDs : Ready, Status • Power on / off button • Calibration button • Control key : FEED
